| Model |
LSYE |
| Rated Load Capacity (kg) |
1500, 2000, 2500, 3000 |
| Precision |
C2/C3 |
| Composition Error |
0.03/0.02 |
| Rated Output Sensitivity (mV/V) |
3.0 ± 0.2 |
| Non-Linearity (%FS) |
0.025 |
| Hysteresis (%FS) |
0.02 |
| Repeatability (%FS) |
0.02/0.01 |
| Creep (%FS/30 min) |
0.03/0.02 |
| Zero Balance (%FS) |
±1.0 |
| Input Resistance (Ω) |
400 ± 10 |
| Output Resistance (Ω) |
350 ± 2 |
| Insulation Resistance (MΩ) |
≥20000 (50VDC) |
| Excitation Voltage (V) |
5 ~ 15 (DC) |
| Compensated Temperature Range (°C) |
-10 ~ +50 |
| Operating Temperature Range (°C) |
-20 ~ +60 |
| Temperature Effect on Zero (%FS/10°C) |
0.02 |
| Temperature Effect on Span (%FS/10°C) |
0.02 |
| Safe Overload (%FS) |
150 |
| Ultimate Overload (%FS) |
250 |
| Protection Class |
IP67 |
| Cable Length |
5m |
