| Rated Load Capacity |
40, 50, 60, 100, 150, 200 tonne |
| Excitation Voltage |
10-12V DC |
| Nominal Output |
1mV/V ± 0.25% |
| Non-Linearity |
±0.50% FSO |
| Hysteresis |
±0.50% FSO |
| Non-Repeatability |
±0.10% FSO |
| Creep (30 Min.) |
±0.05% FSO |
| Zero Balance |
±2.0% FSO |
| Bridge Resistance (40-60T) |
350 ± 10 Ohms |
| Bridge Resistance (100-200T) |
700 ± 20 Ohms |
| Insulation Resistance |
1000M Ohms |
| Compensated Temperature Range |
0°C to 60°C |
| Temperature Effect on Output |
0.01% FSO/°C |
| Temperature Effect on Zero |
0.1% FSO/°C |
| Safe Overload |
150% FSO |
| Ultimate Overload |
200% FSO |
