| Capacities |
100, 200, 500 kg | 1, 2, 5, 10, 20, 30 t |
| Sensitivity |
2.0 ± 1% mV/V |
| Non-Linearity |
0.05% FS |
| Repeatability |
0.03% FS |
| Hysteresis |
0.05% FS |
| Creep (20 Min.) |
0.03% FS |
| Zero Balance |
± 1% FS |
| Insulation Resistance |
> 2000 MΩ (50 VDC) |
| Input Resistance |
400 ± 25Ω (Up to 10t) | 7500 ± 30Ω (20t, 30t) |
| Output Resistance |
350 ± 3Ω (Up to 10t) | 700 ± 3Ω (20t, 30t) |
| Compensated Temperature Range |
-10°C to +60°C |
| Operating Temperature Range |
-30°C to +80°C |
| Temperature Effect on Zero |
± 0.05% FS/10°C |
| Temperature Effect on Output |
± 0.05% FS/10°C |
| Maximum Supply Voltage |
5V ~ 12V (DC/AC) |
| Recommended Supply Voltage |
10V (DC/AC) |
| Safe Overload |
150% FS |
| Maximum Overload |
300% FS |
| Protection Class |
IP67 |
| Cable |
Φ5 x 3m |
