| Model |
STK – 23(C2), 33(C2), 53(C2), 14(C2), 153(C2), 24(C2),
253(C2), 34(C2), 44(C2), 54(C2), 64(C2), 753(C2), 15(C2)
|
| Rated Load Capacity |
0-2, 3, 5, 10, 15, 20, 25, 30, 40, 50, 60, 75, 100 Tonne
|
| Rated Output Sensitivity |
1mV/V ± 0.5% |
| Input Resistance |
350 ± 10 Ohms |
| Output Resistance |
350 ± 5 Ohms |
| Insulation Resistance |
> 1000 Mega Ohms |
| Humidity Rating |
Max 95% RH |
| Excitation Voltage |
10 to 15 Volts DC/AC (RMS) |
| Non-Linearity |
± 0.1% of Rated Output |
| Hysteresis |
± 0.1% of Rated Output |
| Creep |
± 0.1% of Rated Output |
| Non-Repeatability |
± 0.1% of Rated Output |
| Zero Balance |
± 5% of Rated Output |
| Operatable Temperature Range |
-20°C to 65°C |
| Compensated Temperature Range |
0°C to 55°C |
| Temperature Effect on Zero |
0.01% of Rated Output/°C |
| Temperature Effect on Output |
0.01% of Rated Output/°C |
| Safe Overload |
150% of Rated Capacity |
| Ultimate Overload |
200% of Rated Capacity |
| Maximum Side Load Allowed |
1% of Rated Capacity |
| Protection Class |
IP67 |
